Part No. |
Package
|
Size(mm)
|
Reel*Tape(inches*mm)
|
Quantity Per Reel(pcs)
|
Configuration
|
VRWM[max](V)
|
IPP[max](A)
|
IFSM[max](A)
|
VBR[max](V)
|
VBR[max]@IR(mA)
|
IR[max](µA)
|
VCL[max](V)
|
VCL[max]@IPP(A)
|
VESD Air(KV)
|
VESD Contact(KV)
|
TJ[min](℃)
|
TJ[max](℃)
|
Automotive qualified
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
≤
≥
|
≤
≥
|
≤
≥
|
|
|
≤
≥
|
≤
≥
|
||||||
| SOD-123FL | 3 x 1.9 x 1 | 7*8 | 3000 | - | 5 | 21.7 | - | 7.1 | 10 | 200 | 9.2 | 21.7 | ±30 | ±30 | -55 | 150 | Y | |
| SOT-23 | 2.9 x 1.3 x 1 | 7*8 | 3000 | Bidirectional | 26 | - | - | 34.65 | 1 | 0.05 | 46 | 0.87 | - | ±30 | -55 | 150 | Y | |
| SMB | 4.32 x 3.62 x 2.3 | 13*12 | 3000 | Bidirectional | 90 | 4.1 | 100 | 115.5 | 1 | 5 | 146 | 4.1 | - | - | -55 | 150 | Y | |
| SMB | 4.32 x 3.62 x 2.3 | 13*12 | 3000 | Unidirectional | 90 | 4.1 | 100 | 115.5 | 1 | 5 | 146 | 4.1 | - | - | -55 | 150 | Y | |
| SMA | 4.3 × 2.65 × 2.1 | 13*12 | 5000 | Bidirectional | 150 | 1.6 | 40 | 185 | 1 | 5 | 243 | 1.6 | - | - | -55 | 150 | Y | |
| SMA | 4.3 × 2.65 × 2.1 | 13*12 | 5000 | Unidirectional | 150 | 1.6 | 40 | 185 | 1 | 5 | 243 | 1.6 | - | - | -55 | 150 | Y | |
| SOD-323 | 1.7 x 1.25 x 0.95 | 7*8 | 3000 | Asymmetrical bidirectional-cathod2(24V) | 24 | - | - | 30.3 | 5 | 0.05 | 40 | 1 | ±25 | ±23 | -55 | 125 | Y | |
| SOD-323 | 1.7 x 1.25 x 0.95 | 7*8 | 3000 | Asymmetrical bidirectional-cathod1(15V) | 15 | - | - | 20.3 | 5 | 0.05 | 25 | 1 | ±25 | ±23 | -55 | 125 | Y |
