Part No. |
Package
|
Size(mm)
|
Reel*Tape(inches*mm)
|
Quantity Per Reel(pcs)
|
VR[max](V)
|
IF[max](mA)
|
IFSM[max](A)
|
IR[max](µA)
|
IR[max]@VR(V)
|
VF[max](V)
|
VF[max]@IF(mA)
|
Cd[max](pF)
|
TJ[min](℃)
|
TJ[max](℃)
|
Automotive qualified
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
≤
≥
|
≤
≥
|
≤
≥
|
≤
≥
|
≤
≥
|
≤
≥
|
≤
≥
|
≤
≥
|
||||
| TO-252 | 6.1 x 6.6 x 2.3 | 13*16 | 2500 | 60 | 10 | 150 | 100 | 60 | 0.7 | 100000 | 400 | -55 | 150 | Y | |
| SMC | 6.86 x 6.11 x 2.34 | 7*16 / 13*16 | 850 / 3000 | 40 | 3000 | 80 | 100 | 40 | 0.55 | 3000 | 200 | -65 | 150 | Y | |
| SMA | 4.3 x 2.65 x 2.1 | 7*12 / 13*12 | 1800 / 5000 | 40 | 2000 | 50 | 100 | 40 | 0.55 | 2000 | 170 | -65 | 150 | Y | |
| SOT-23 | 2.9 x 1.3 x 1 | 7*8 | 3000 | 30 | 200 | 0.6 | 2 | 25 | 0.4 | 10 | 10 | -55 | 125 | Y | |
| SOT-23 | 2.9 x 1.3 x 1 | 7*8 | 3000 | 30 | 200 | 0.6 | 2 | 25 | 0.4 | 10 | 10 | -55 | 125 | Y | |
| SOT-23 | 2.9 x 1.3 x 1 | 7*8 | 3000 | 30 | 200 | 0.6 | 2 | 25 | 0.4 | 10 | 10 | -55 | 125 | Y | |
| SOT-23 | 2.9 x 1.3 x 1 | 7*8 | 3000 | 30 | 200 | 0.6 | 2 | 25 | 0.4 | 10 | 10 | -55 | 125 | Y |
